Features
|
- 500 ~ 10000 RPM spinning speed programmable
- Accept substrate from 5 mm to 5"
- PP chamber for anti-corrosive operation.
- One gas inlet port on top of cover which can fill inert gas during coating
- One 20ml Plastic Syringe is included
- Safety interlock is integrated into the lid
|
|
Vacuum
Chuck
|
- Chamber size: 150 mm diameter
- Click the picture below right to watch demo video for how to use 9mm vacuum chuck hold 5mm sample.
|
|
Vacuum
Pump
|
- One 120L/min Oilless Vacuum Pump is included in the standard package, please click the picture
below for specification details.
- For Ar glove box user, Please consider our 24VDC vacuum pump to be used inside a glovebox without feedthrough.
- Vaccum grade rubber pipe is included for immediate use
|
|
Programmable
Contro
|
- Duration up to 60 seconds
- Acceleration: 100 - 2000 rpm / sec adjustable
- Accuracy: < 5%
- Digital control panel can store 12 programs and each program has 6 segments programmable for speeds,
acceleration, and spin duration (please click picture below-right to see typical program setting)
|
|
Input Power
|
- AC 220V (Please email us for AC 110V Version)
- 1000 W total for oilless pump and spin cater
- 24VDC high speed motor
|
|
Gas Inlet
|
6mm diameter gas inlet port allows customers to fill desired gas into the chamber,
which can make coating under variable gas flow environment
|
|
Liquid
Injection
|
- Standard Package: 20ml plastic syringe with needle
- Option 1: Precision Electronic Single Channel Pipette: 20 - 200uL
- Option 2: Heatable glass syringe with temp. controller, up to 200C
|
|
|
- Option 1: PE Heating cover with digital temperature controller up to 120°C(<10 minutes) is available upon request
at extra cost. This is a short drying process (usually takes several seconds or Max.10 minutes) which can dry and
solidify the coating and remove the residual solvent after coating process is completed. Click demo video & picture
below for detail.
- Option 2: PTFE Heating cover + PTFE vacuum chuck set is capable of drying temperature up to 200°C(< 5 minutes).
Vacuum chuck and chamber also need to be replaced by PTFE material to withstand high heating temperature.
Please click PTFE Heating cover and chuck set to learn.
- Option 3: Heatable syringe with digital temperature controller up to 200C is available upon request at extra cost.
It provides the pre-heat solution during the coating process. Click pictures & demo video for details.
- Option 4: Vacuum Flash Assembly for DIY Vacuum Flash-Assisted Solution Process (VASP), Up to 5 mTorr is available
|
|
Product
Dimensions
|
450mm Depth ×280mm W ×340mm H
|
|
Net Weight
|
20 kg
|
