Laboratory Pressing Machine For Coin Cell Electrode Lab Press

Model Number:: TMAX-YP180
Dimension(L*W*H):: 232*165*320mm
Net Weight:: 45 kg (100 lbs)
Compliance:: CE certificate
Warranty:: Two Year Limited Warranty With Lifetime Support
Payment:: T/T, Credit Card, Paypal, LC, Western Union
Delivery Time:: 3 Days

Email:: David@battery-equipments.com
WhatsApp:: +8618659217588
WeChat:: 18659217588

Product Description

Laboratory Pressing Machine For Coin Cell Electrode Lab Press

1 TMAX-YP180 Hydraulic press machine is a desktop manual pressing machine for materials / chemistry research laboratories to prepare compound ceramic sample.

2 The Hydraulic press machine is mainly used for laboratory tablet battery materials manual press, and Pressure powdery cake. It is mainly used for coin cell/ button battery electrode lab press.

3 The Manual press machine mould can be customized according to customer’s requirements.

Model	Hydraulic press machine TMAX-YP180
Press die size	Diameter 68mm, customized
Press stroke	30mm
Advantages	By using aluminum alloy and high strength steel, surface after the environmental protection electroplating processing will never rust Using high quality imported mould material
Rocker Pressure	<6kg
Max Pressure	200kg/cm2 (The hydraulic drive pressure up to 8T, the battery sealing no vibration, no leakage)
Working Pressure	80-100kg/cm2
Dimension(LWH)	232165320mm
Weight	28kg
Shipping Weight	35kg
Warranty	One Year limited warranty with lifetime support
